Reliable data transmission thanks to special shielding
4/5/2012 |
|
|
Belden has added new Gigabit Ethernet connectors to its Lumberg Automation™ product range. These connectors, which support data rates of up to 10Gbps, have a compact design with special shielding that also covers the individual wire pairs, thus guaranteeing reliable data transmission even where there are strong electromagnetic fields.
They are offered with M12 or RJ45 connection technology, and in both molded and self-assembly versions, optionally including individual cable lengths, making them flexible and quick to put into operation. Other features include a robust design, a wide operating temperature range of from 30º to +90ºC and - for the M12 versions - industrial protection class IP67. The Gigabit Ethernet connectors thus facilitate highly available and cost-effective solutions for a host of applications, such as connecting IP cameras and infotainment systems in rail vehicles - approval under EN 50155 has been applied for - or wiring up complex machines and systems.
The self-assembly M12 versions, with eight-pole connectors and couplings with x-coding and screw connectors, have a threaded joint. Cables are made up either using cut and clamp or - for the flanged versions - via print contacts. The molded M12 connectors also have eight-pole x-coding and, like the corresponding RJ45 versions, are available with made-up cables on one or both ends. A version with an M12 and an RJ45 connector is also available.
The molded M12 connectors and the RJ45 versions have bodies made of thermoplastic polyurethane (TPU), while the self-assembly connectors are of nickel-plated die-cast zinc or brass (flange version). The optionally attached cables are made of halogen-free polyurethane (PUR) with AWG 26 cores. This also applies to the cables for the molded connectors, which are offered in lengths of 2, 5 or 10 meters.
With the launch of these new screened Gigabit Ethernet connectors from Lumberg Automation™, Belden is now marketing a comprehensive product portfolio that offers ideal solutions for a variety of requirements. Product Manager Joachim Kiera says: "These connectors can turn your network into a veritable data freeway because they all ensure maximum bandwidth. Since they are also extremely robust, they can be used even under the most rugged environmental conditions." |
|
|
|
|
|
