Hydraulic cold elbow forming machine
Model: YLT
|
|
Elbow cold forming machines (elbow making machines) are designed and constructed for cold forming small radius elbows with curvature of 1.0D to 1.5D and with diameter from 1/2" to 28" of stainless steel, cabon steel, alloy steel, etc. The production standard will be ASME B16.9, ASME B16.28, DIN2605, SMS, 3A, customized drawings is preferable, These produced elbows will be widely used in the connection of the industrial pipelines for the Petrochemical, Gas and Oil pipes, Electrical Power, Food, etc.
Main Features of Elbow cold forming machines (Elbow making machine):
1.Elbow cold forming machie has attained the CE and ISO certificates;
2.High strength steel metal via gas shielded welding framed machine base is used on Elbow cold forming machie;
3.high rigidity and load balance are the main design features of the Elbow cold forming machie in order to keep excellent accurancy;
4.Elbows can be formed in one cold forming process with no needs for any calibration
5.Elbow cold forming machie has the features of energy saving, high working efficiency, less labor cost, batch production
6.Elbow cold forming machie adopts imported hydraulic system and electric appliances.
7.Elbow cold forming machie adopts PLC button centralized control, uses touch screen, applys proportional valve to regulate pressure. It can be adjusted and operated manually and automatically.
We also supply:
Tee cold forming machine, hot mandrel elbow machine, induction tube bending machine, elbow chamfering machine, tee beveling machine, reducer beveling machine, pipe&tube processing machine, pipe end facing machine ,die moulds and mandrils, pipe fittings. |
|
